001-8680-04 - Wireless Control Valve - 4-Function

4-Function Wireless Control Valve System will allow you to control a hydraulic hand lever remotely. The system comes complete with two actuators, a wireless controller, and all the mounting hardware.

PRODUCT DESCRIPTION
4-Function Wireless Hydraulic Control Valve System will allow you to control two hydraulic hand levers remotely. The system comes complete with two actuators, a wireless controller, and all the mounting hardware. Connector pin-outs:

1. Red - 12VDC to motor
2. Black - Ground to motor
3. Green - 12VDC to clutch
4. White - Ground to clutch

ACTUATOR SPECIFICATIONS

• Operating voltage: 10.3 – 16 VDC, 12VDC nominal
• Output Force (Dynamic) Load: 60-lbf @ 3 amp (267 N)
• Output Force (Holding) Load: 150 lbs (68 kg)
• Motor current (at rated load): 2.25 amps
• Motor locked rotor current: 18 amps
• Clutch current: 0.6 amp
• Stroke (max): 2.5 inches (63.5 mm)
• Maximum no load speed: 1.5 inches/second (38.1 mm/s)
• Weight: 3.6-lbs (1.6 kg)
• Operating Temp Range: -40°F to 158°F (-40°C to 70°C)
• Mounting: Pivot mount
• Construction: Aluminum die cast housing E-coated for corrosion resistance
• Permanently lubricated metal gear drive
• Stainless steel output shaft
• Sealed construction
• Dust proof and splash proof
• Industrial grade rod seal
• 4-start
• Availability: Built-to-order. (3 week lead time)
